ContactPost: Civil Aviation Authority of Viet Nam Telephone: +84 24 38274191 Fax: +84 24 38274194 Email: and@caa.gov.vn Web: http://caa.gov.vn | AIP Supplement for VIET NAM | AIP SUP 38/24 Effective from 31 OCT 2024 to 15 AUG 2025 Published on 03 OCT 2024 |
This section supplements the following portion(s) of the AIP: AD.
On 19 SEP 2024, AIRAC AIP SUP 35/24 was published to notify the establishment of flight procedures charts, aerodrome operating minima temporarily applied during construction of T2 terminal at Noi Bai aerodrome (VVNB) due to crane operation.
The construction used 30-ton, 100-ton, 150-ton and 350- ton cranes are 90m compare to MSL.
Therefore, this AIP Supplement aims at notifying the establishment of cranes to serve the construction to extend T2 at Noi Bai International Airport (VVNB):
Zone 1: On the West of T2 limited by the line connecting points W42-W52/A-F.
Zone 2: On the West of T2 limited by the line connecting points W06-W10/F-O.
Zone 3: On the East of T2 limited by the line connecting points E06-E10/F-O.
Zone 4: On the East of T2 limited by the line connecting points E37-E45/A-F.
| NR |
Area |
Point |
Radius |
Coordianates |
Scope |
HGT (M) |
|---|---|---|---|---|---|---|
| 1 | ZONE 1 | E | 27 M | 211310.00N 1054716.59E |
Move from E to F | 75.2 M |
| F | 211311.31N 1054712.07E |
Move from F to G | ||||
| G | 211313.27N 10547'12.71E |
Move from H to G | ||||
| H | 211312.08N 1054716.82E | |||||
| 2 | ZONE 2 | I | 40 M | 211306.07N 1054728.83E |
Move from I to J | 90 M |
| J | 211304.01N 1054728.15E | |||||
| M1 | 211302.75N 1054726.33E |
Move in areas surrounded by 4 points M1, N1, O1, P1 | ||||
| N1 | 211302.30N 1054727.89E | |||||
| O1 | 211301.76N 1054727.71E | |||||
| P1 | 211302.21N 1054726.15E | |||||
| 3 | ZONE 3 | K | 40 M | 211303.85N 1054736.37E |
Move from K to L | 90 M |
| L | 211301.80N 1054735.70E | |||||
| M2 | 211300.25N 1054734.96E |
Move in areas surrounded by 4 points M2, N2, O2, P2 | ||||
| N2 | 211259.80N 1054736.52E | |||||
| O2 | 211259.26N 1054736.34E | |||||
| P2 | 211259.71N 1054734.79E | |||||
| 4 | ZONE 4 | A | 27 M | 211302.64N 1054749.87E | Move from A to B | 75.2 M |
| B | 211302.26N 1054751.21E | Move from B to C | ||||
| C | 211300.24N 1054750.54E | Move from C to D | ||||
| D | 211301.22N 1054747.14E | |||||
| B1 | 211302.02N 1054752.03E | Stand at B1 |
This AIP Supplement shall become effective from 0100 on 31 OCT 2024 to 1000 on 15 AUG 2025.
Any change relating to this AIP Supplement shall be notified by NO TAM.
