AIP Supplement for VIET NAM

AIP SUP

34/24

Effective from 05 OCT 2024

to 28 DEC 2024

Published on 20 SEP 2024

  CONSTRUCTION OF RWY 35R/17L AT DA NANG INTERNATIONAL AIRPORT (VVDN)

1 — INTRODUCTION

This section supplements the following portion(s) of the AIP: AD.

This AIP Supplement aims at notifying the construction of cement concrete panels on RWY 35R/17L at Da Nang International Airport (VVDN).

2 — DETAIL

Note:

  1. Construction areas are surrounded by fences, marker boards, warning lights, markings as specified.

  2. Pilot follow ATC instructions strictly.

2.1  Construction area

Repairing of cement concrete panels on RWY 35R/17L (approximately 366 M to the North of TWY CL E1 and approximately 933 M to the South of TWY CL E6).

2.2  Construction period: From 0000 on 05 OCT 2024 to 1000 on 28 DEC 2024.

2.3  Temporarily suspended areas

  1. RWY 35R/17L (except for the intersection with TWYs E1, G1 and the intersection with TWYs E6, G6 which are remain available for aircraft and vehicle movement).

  2. TWYs E2, E3, E4, G2, G4.

  3. Shut down ILS of RWY 35R; Approach lighting system, PAPI lighting, RWY 35R/17L lighting.

Note: All aircraft shall not be allowed to operate on TWY W when aircraft are approaching to land or in the process of taking-off from RWY 35L/17R.

2.4  Operational procedures during construction

  1. For aircraft from RWY to apron

    1. For landing aircraft

      + RWY 17R: After landing → TWY G1 → Cross RWY 35R/17L → TWY E1 → TWY E → Apron.

      + RWY 35L:

      1. After landing → TWY G6 → Cross RWY 35R/17L → TWY E6 → TWY E → Apron, or

      2. After landing → TWY G6 → Turn left and taxi on RWY 35R/17L → TWY E7 → TWY E → Apron.

    2. For take-off aircraft:

      + RWY 17R:

      1. Apron → TWY E → TWY E6 → Cross RWY 35R/17L → TWY G6 → The beginning of RWY 17R for take-off, or

      2. Apron → TWY E → TWY E7 → Taxi on RWY 35R/17L → TWY G6 → The beginning of RWY 17R for take-off.

      + RWY 35L: Apron → TWY E → TWY E1 → Cross RWY 35R/17L → TWY G1 → The beginning of RWY 35L for take-off.

  2. For aircraft on apron

    Applied as current procedure, following ATC instructions strictly.

3 — EFFECT

This AIP Supplement shall become effective from 0000 on 05 OCT 2024 to 1000 on 28 DEC 2024.

4 — CANCELLATION

This AIP Supplement supersedes NOTAM A2380/24.

Any change relating to this AIP Supplement shall be notified by NOTAM.

This AIP Supplement consists of attachment as follows:

Layout of construction areas.



Figure 1. Layout of construction area: From 0000 on 05 OCT 2024 to 1000 on 28 DEC 2024
